Zirconia Powder Refractory Raw Material
, Ultrafine Zirconia Powder
, Ultrafine Yttria Stabilized Zirconia Powder
Zirconia Powder Refractory Raw Material Ultrafine Yttria Stabilized Zirconia Powder
China Factory Wholesale High Quality Zirconia Powder Yttria Stabilized Ultrafine Zirconia Powder
Zirconia has the characteristics of high hardness, high-temperature resistance, chemical corrosion resistance, wear-resistance, small thermal conductivity, strong thermal shock resistance, good chemical stability, outstanding composite material, etc. The properties of the material can be improved by combining nanometer zirconia with alumina and silicon oxide. Nano zirconia is not only used in structural ceramics and functional ceramics. Nano zirconia doped with different elements conductive properties, used in solid battery electrode manufacturing.
Features of High Quality Zirconia Powder:
1. Small particle diameter, narrow distribution range, activity, stable.
2. Excellent liquidity and compactness, easy to mold and sinter.
3. BET and particle size of airflow or granulation one can be controlled on customers's request.
Product Applications of High Quality Zirconia Powder
In recent years, Zirconia Ceramics are increasingly used for biomedical applications . Zirconia is used as a biomaterial. It has advantages over other ceramics because of its high mechanical strength and fracture toughness. Biomaterials have been proposed as artificial bone fillers for repairing bone defects. Zirconia also finds other clinical applications such as: arthroplasty, dental crowns.
Though zirconia and Yttria stabilized Zirconia have orthopedic applications such as hip and knee prostheses, hip joint heads, temporary supports, tibial plates, dental crowns, not much literature reports are available on the studies of this oxide ceramics as drug carriers. etc. Zirconia toughened alumina ceramic foams can be used in potential bone graft applications. Thin films of ZrO2 (Zirconia) have beneficial ceramics properties that offers various possibilities for
Technological application such as optical coating, thermal barrier, catalysis or catalytic supports.
Yttria-stabilized zirconia thin films by dip-coating for IT-SOFC application . Solid oxide fuel cell (SOFC) ceria/yttria stabilized zirconia electrolytes for solid oxide fuel cell applications . Zirconia is used as air-fuel ratio sensors for Progress in Synthesis and Applications of Zirconia 26 automotive applications . To combine the mechanical properties of a high strength inert ceramic with the specific properties of bioactive glasses, composite materials based on high-density zirconia substrates coated by bioactive glasses are reported to be used . Zirconia ceramics can be used for functional as well as structural applications.
Parameters of High Quality Zirconia Powder
(1)Yttrium Stabilized Polycrystalline Ultrafine Zirconia Powder
| Item |
Classification |
| 3YZ-TPZ |
5YZ-TPZ |
8YZ-TPZ |
| ZrO2 wt% |
84.3~84.7 |
90.6~91.0 |
86~86.4 |
| Y2O3 wt% |
5.18~5.22 |
8.6~9.0 |
13.3~13.7 |
| Al2O3 ppm |
＜100 |
0.05~0.45(wt%) |
0.05~0.45(wt%) |
| Fe2O3 ppm |
＜50 |
＜50 |
＜50 |
| SiO2 ppm |
＜200 |
＜200 |
＜200 |
| TiO2 ppm |
＜50 |
＜50 |
＜50 |
| Na2O ppm |
＜50 |
＜50 |
＜50 |
| K2O ppm |
＜100 |
＜100 |
＜100 |
| CeO ppm |
＜100 |
＜100 |
＜100 |
| MgO ppm |
＜100 |
＜100 |
＜100 |
| Cr ppm |
＜500 |
＜500 |
＜500 |
| BET m2/g |
5~30 |
10~32 |
10~32 |
| Granularity D50 μm |
＜0.5 |
| PH |
6.5 |
| Apparent Density g/cm3 |
1.15~1.25 |
(2) Partially Stabilized Zirconia(PSZ)and Zirconia Toughened Alumina(ZTA)
| Item |
Specification |
| Ce13 |
Ce85 |
ZTA20 |
ZTA30 |
| ZrO2 wt% |
86~88 |
13.5~14.5 |
18~20 |
27.4~29.4 |
| Y2O3 wt% |
/ |
/ |
1~1.2 |
1.4~1.6 |
| CaO % |
＜0.01 |
| MgO % |
＜0.01 |
| CeO2 % |
12~14 |
84.5~85.5 |
/ |
/ |
| Al2O3 % |
＜0.01 |
79.5~80.5 |
69.5~70.5 |
| SiO2 % |
＜0.015 |
| Fe2O3 % |
＜0.002 |
| TiO2 % |
＜0.005 |
| Na2O % |
＜0.001 |
| Cr % |
＜0.02 |
| D50 μm |
0.5~1 |
| Lgloss % |
＜1.0 |
(3) High Purity Ultrafine Zirconia Powder
| Item |
Specification |
| ZrO2 wt% |
≥99.7 |
| Y2O3 wt% |
/ |
| Al2O3 ppm |
＜100 |
| Fe2O3 ppm |
＜50 |
| SiO2 ppm |
＜200 |
| TiO2 ppm |
＜100 |
| Na2O ppm |
＜50 |
| K2O ppm |
＜100 |
| CeO ppm |
＜100 |
| MgO ppm |
＜100 |
| Cr ppm |
＜500 |
| BET m2/g |
5~15 |
| Granularity D50 μm |
＜0.5 |
| PH |
6.5 |
| Apparent Density g/cm3 |
0.5~1.0
|
